Armored thermocouples, as core sensors in the field of temperature measurement, occupy an important position in both industrial and civilian scenarios due to their outstanding performance. It is made by closely combining seamless metal sleeves, insulating materials and thermocouple wires through drawing process, and can quickly capture temperature changes under complex working conditions. Meanwhile, the product features excellent flexibility, allowing for free bending and winding. It breaks through the installation limitations of traditional straight-rod thermocouples and can closely fit the surface of irregular-shaped equipment or narrow Spaces. With irregular mechanical shaping, it meets the temperature monitoring requirements of complex scenarios.

Introduction

Armored thermocouple, because of its littel outer diameter, its response time is very fast and stable. It is anti-vibration,corrosion-resistant and can be bended freely, so it is special for irregular form substance,such as g liquid or solid surface within a certain renge.

Application

In recent years, thermocouples have been used in various industries such as household appliances, industrial heaters, combustion machinery, automobiles, petrochemicals, ships, steelmaking, and atomic energy.

Technical Parameter

Inorganic insulating thermocouple	Connection section	0.22mm²
	Minimum bending radius	5.0* Surface diameter
	Tolerance level	Level 1 or 2
Surface insert thermocouple	Temperature range	0-400℃/32-750°F
	Connection section	0.22mm²
	Diameter	2,3,3.5,4,5,6mm
	Length	Max. 500mm
	Wiring options	Fiberglass wire /DHG, Teflon, silicone
	Sensor type	L,J,K
	Temperature measuring point	Bottom, grounded or ungrounded
	Tolerance level	Level 2
Plug-in thermocouple	Temperature range	0-400℃/32-750°F
	Connection section	0.22mm²
	Connection structure	Multiple strands of wire, fiberglass insulated wire with metal woven sleeve
	Sensor structure	25-200mm/0.98-7.87inch Inner diameter of fixed cap: 12.2mm Compression spring: 200mm/7.87inch Insertion depth: 25-200mm/0.98-7.87inch
	Temperature measuring point	Bottom, grounded or ungrounded
	Tolerance level	Level 2
Right angle thermocouple	Temperature range	0-400℃/32-750°F
	Connection section	0.22mm²
	Connection structure	Multiple strands of wire, fiberglass insulated wire with metal woven sleeve
	Sensor structure	Hemispherical, screw-in mount, M8X1 thread, flexable protective spring
	Temperature measuring point	Bottom, grounded or ungrounded
	Tolerance level	Level 2
Ring thermocouple	Temperature range	350℃/660°F
	Connection section	0.22mm²
	Connection structure	Multistranded, fiberglass insulated wire with metal woven casing and shrink casing
	Temperature measuring point	Bottom, grounded or ungrounded
	Tolerance level	Level 2
Veneer type thermocouple	Temperature range	0-400℃/32-750°F
	Connection section	0.22mm²
	Connection structure	Multiple strands of wire, fiberglass insulated wire with metal woven sleeve
	Sensor structure	15300.5mm, Bending Ø100mm^±^5mm, bending protection spring
	Temperature measuring point	Bottom, grounded or ungrounded
	Tolerance level	Level 2
Clamp type thermocouple	Temperature range	0-350℃
	Connection section	0.22mm²
	Connection structure	Multiple strands of wire, fiberglass insulated wire with metal woven sleeve
	Sensor structure	Have clamp, 9mm wide, with a flexible spring protection
	Temperature measuring point	Bottom, grounded or ungrounded
	Tolerance level	Level 2
Flange mounted thermocouple	Temperature range	0-400℃/32-750°F
	Connection section	0.22mm²
	Connection structure	Multiple strands of wire, fiberglass insulated wire with metal woven sleeve, bend-able protection spring
	Sensor structure	Hemispherical, fixed plate and sensor at 90 degrees, drilling M4
	Temperature measuring point	Bottom, grounded or ungrounded
	Tolerance level	Level 2
